Clutches for 2018 Ram ProMaster 1500

No.

Part # / Description / Price

Price

Reverse Clutch Snap Ring

4377195

Fwd. [1.53-1.58]mm. [1.53-1.58mm].

$8.75

Reverse Clutch Snap Ring

4412873

Fwd. 2.27-2.32mm. [2.27-2.32]MM. 2.27-2.32mm. [2.27 - 2.32MM] Thick.

$8.09

Reverse Clutch Snap Ring

4412871

Fwd. [1.77 - 1.83mm].

$7.81

Reverse Clutch Snap Ring

4412872

Fwd. 2.02-2.07mm. [2.02-2.07]MM. 2.02-2.07mm. [2.02 - 2.07MM] Thick.

$30.86

Transmission Clutch Reaction Plate

4377194

Fwd. [5.49 - 5.75 MM] Thick. 2nd & 4th Clutch. Reverse Clutch Reaction. [2.02-2.07 mm].

$35.42

Clutch Disc

4531678AB

Fwd. UnderDrive. Transmission Reverse Clutch.

$13.97

Transmission O/Drive Clutch Plate

4659053

Fwd. Underdrive. Reverse,.

$11.00

No.

Part # / Description / Price

Price

Underdrive Clutch Snap Ring

4659934

Tapered. Fwd.

$15.62

Underdrive Reaction Plate Package

4883015AB

Fwd. 6.70-6.80.

$53.57

Underdrive Reaction Plate Package

4883013AB

Fwd. 5.72-5.82.

$44.50

Underdrive Reaction Plate Package

4883014AB

Fwd. 6.21-6.31.

$61.38

Underdrive Clutch Snap Ring

4659980

Fwd. Flat. 1.53/1.58MM]. Flat. [1.53-1.58]MM.

$7.81

Auto Transmission Clutch Package

68225794AA

AUTO TRANSMISSION

$12.54

No.

Part # / Description / Price

Price

Snap Ring

6501702

Fwd. Input Shaft. UnderDrive Piston, Inner, 45mm O.D. Intermidiate Shaft Retaining.

$7.81

Snap Ring

6507226AA

Input Clutch Retainer to Hub. Fwd.

$12.10

Transmission Input Clutch Retainer

4659935AB

Fwd.

$94.66

Reverse Servo Piston Seal

4659056

Fwd. Reverse and Overdrive Piston, Outer 160mm. Input Clutch, Outer, 160mm O.D. Reverse & OverDrive Piston, Outer, 160mm O.D,.

$17.71

Reverse & O/Drive Clutch Piston O Ring

6033158

Fwd. Reverse & OverDrive Clutch Piston, Inner. Transmission. [OD=M78.91 THK=2.70].

$23.71

Input Clutch Hub Package

5017518AB

Fwd.

$214.50

Transmission Clutch O Ring

6502269

Fwd. Input Clutch Hub, Red, .106`. Input Clutch Hub, Small, Rear Red .103`` Thick. [ID=M57.85 THK=2.258] / Transmission Input Clutch To Retainer.

$21.51

Transmission Clutch O Ring

6502271

Fwd. Input Clutch Hub, Large, Front Blue, .103`` Thick. [M61.08 C/S 2.70] / Transmission Input Clutch To Retainer.

$29.76

Overdrive Piston Spring

4412202AB

Fwd. Reverse & OverDrive Piston Return.

$31.24

Snap Ring

4412203

Fwd. Reverse & OverDrive Piston Return Spring.

$7.43

Input Shaft Package

68004290AA

22 TEETH

$85.47

Input Shaft Seal

4446543

Fwd.

$7.54

No.

Part # / Description / Price

Price

Thrust Bearing

4412209

Front Planet Pinion Carrier. Fwd. Support to Input Clutch Hub, Needle Thrust.

$15.07

Transmission O/Drive Clutch Plate

3836240AB

[2.36mm to 2.43mm]. 1.92 - 1.99mm. 2.36-2.43mm Thk. [2.36/2.46 mm]. [2.14/2.21mm]. [2.36/2.43 mm.

Discontinued

Transmission O/Drive Clutch Plate

3836241AB

[2.58mm to 2.65mm]. 2.03 - 2.10mm. 2.58-2.65mm Thk. [2.58/2.65] mm. [2.36/2.43mm].

Discontinued

Transmission O/Drive Clutch Plate

3836237AB

[1.70mm to 1.77mm]. 1.59 - 1.66mm. 1.70-1.77mm Thk. [1.70/1.77] mm.

Discontinued

Transmission O/Drive Clutch Plate

4431666AB

[1.81mm to 1.88mm]. 2.25 - 2.32mm. 1.69-1.91mm. [1.81/1.88] mm. [1.81/1.88mm]. [1.81/.188mm].

Discontinued

Transmission O/Drive Clutch Plate

4431668AB

[2.52/2.32 mm]. [2.25mm to 2.32mm]. [2.22/2.32mm]. 2.47 - 2.54mm. 2.13-2.35mm. 2.25-2.32mm Thk. [2.25/2.32] mm.

Discontinued

Transmission O/Drive Clutch Plate

4431667AB

[1.97/2.08 mm]. [2.03mm to 2.10mm]. 2.36 - 2.43mm. 1.91-2.13mm. 2.03-2.10mm Thk. [2.03/2.10] mm.

Discontinued

Transmission O/Drive Clutch Plate

3836238AB

[1.92mm to 1.99mm]. [1.90/1.99mm]. 1.70 - 1.77mm. [1.92/1.99] mm. [1.92/1.99mm].

Discontinued

Transmission O/Drive Clutch Plate

3836239AB

[2.14/2.99mm]. [2.14mm to 2.21mm]. 1.81 - 1.88mm. 2.14-2.21mm Thk. [2.24/2.21 mm]. [2.14/2.21] mm. [2.14/2.29mm]. [1.92/1.99mm].

Discontinued

Transmission O/Drive Clutch Plate

4446671AB

[2.91mm to 2.98mm]. 2.58-2.65mm Thick. 2.79-3.01mm. [2.91/2.98] mm. 2.91 - 2.98mm].

Discontinued

Transmission O/Drive Clutch Plate

4431665AB

1.37-1.44mm Thick. 1.37-1.44mm Thk.

Discontinued

Transmission O/Drive Clutch Plate

4431669AB

$13.97

Transmission O/Drive Clutch Plate

4446670AB

[2.69mm to 2.72mm]. [2.69/2.72mm]. 2.57-2.79mm. 2.58-2.65mm Thick. [2.69/2.76] mm. 2.69/2.76mm].

Discontinued

Second And Fourth Clutch Hub And Gear

4659618AB

Fwd.

$54.45

Second And Fourth Clutch Thrust Washer

4412216AC

Use after Build Date 04/28/2008. Use Before Build Date 04/28/2008.

$14.52

Snap Ring

04505591AB

Fwd. 2nd & 4th Clutch Piston Retainer.

$12.43

2nd & 4th Clutch Piston Retainer Package

68020279AA

$30.14

2nd And 4th Clutch Piston Spring

4412248

Fwd.

$33.72

Auto Transmission Clutch Package

68004330AA

$47.30

No.

Part # / Description / Price

Price

Overdrive Clutch Hub And Shaft

4659993AC

Fwd. With Shaft, OverDrive Clutch.

$109.23

Thrust Plate And Washer Package

5018923AB

Thrust Plate And Washer Kit

Fwd.

$21.07

Underdrive Clutch Hub And Shaft Package

4864936AE

Underdrive Clutch Hub And Shaft Kit

Fwd. With Shart and Thrust Washer. With Shaft & Thrust Washer, UnderDrive Clutch. With Shaft & Thrust Washer, Under Drive Clutch.

$54.45

Thrust Bearing

4800082AA

Trans Input Clutch # 2.

$15.07

Snap Ring

6501715

Underdrive Piston Spring Retainer. Fwd.

$10.01

Transmission U/Drive Spring Retainer And Seal

4431612

Fwd.

Backordered

Transmission U/Drive Spring Retainer And Seal

04431612AC

Fwd.

$48.29

Drive Lower Case Spring

4377177

Fwd. Underdrive Piston Return.

$27.83

Underdrive Piston

4431611

Fwd. Also Avalable In Overhaul Package. Also Avalable In Overhaul Packge. Also Available in Overhaul Package.

$62.10

Piston Outer Seal

4659871

140mm OD. Fwd.

$17.44

Under Drive Seal

4659391AB

Fwd. UnderDrive Piston, Inner, 45mm O.D.

$13.97

No.

Part # / Description / Price

Price

Snap Ring

4505622

Fwd. Reverse & Over Drive Preassure Plate, Flat. Rev. & OverDrive Pressure Plate, Flat. Reverse & Overdrive Preassure Plate, Flat.

$7.37

Reverse & Overdrive Clutch Pressure Plate

4800497AA

$44.06

Snap Ring

4505621

Fwd. Reverse & Over Drive Clutch Pressure Plate, Wave. Rev.& OverDrive Clutch Pressure Plate, Wave. Peverse & Overdrive Clutch Pressure Plate, Wave. Reverse & Overdrive Clutch Preassure Plate, Wave.

$7.65

Overdrive Clutch Disc Package

68010495AA

Backordered

No.

Part # / Description / Price

Price

Snap Ring

4800378AA

$17.71

Reaction Plate

5078829AA

[5.883mm]. 5.883 mm.

$40.04

Reaction Plate

5078831AA

[6.403mm]. 6.403 mm.

$39.71

Reaction Plate

5078833AA

[6.923mm]. [6.923 mm]. 6.932 mm.

Backordered

Reaction Plate

5078832AA

6.663 mm.

Backordered

Reaction Plate

5078830AA

6.143 mm.

Backordered

Snap Ring

4412395

Fwd. Low & Reverse Clutch, 6-1/2`` O.D.

$8.80

Automatic Transmission Clutch Package

68004331AA

Lowith Reverse.

$51.32

Snap Ring

6501853

Fwd. Low & Rev. Clutch.

$7.37

Low/Reverse Clutch Piston Spring

4800236AA

$36.85

Low And Reverse Clutch Piston

5078591AA

$47.58

Pan Head Screw And Washer

6501819

M5x0.8x11.00. Fwd.

$5.34

Transmission L/R Clutch Retainer W/Gasket Retainer Pkg

68800255AA

TRANSMISSION LOW AND REVERS

$30.80

Clutch Retainer Gasket W Isheet Gasket Pkg

68003039AA

CLUTCH RETAINER GASKET W IS

$13.59
